The award-winning Black Box® Emerald® DESKVUE, a completely new concept in KVM over IP, allows users to create a personalized workspace in which they can simultaneously monitor and interact with up to 16 systems - physical, virtual, and cloud-based - of their choice.
Ideal for control room environments, the Black Box receiver ensures instant, error-free switching between systems with a simple mouse click and enables free positioning of system windows across four 4K screens, including ultrawide curved monitors, while providing unique source information for each connected system. Because the Emerald DESKVUE receiver does away with constant switching between systems, users no longer need to spend 40% to 50% of their time switching between systems and monitoring when tasks are complete or when a system requires interaction. With flexible, concurrent access to more than a dozen systems, all within view and easy reach, users maintain complete situational awareness that allows them to improve efficiency and productivity on a day-to-day basis and to take action instantly whenever needed. Unlike solutions created out of complex and costly equipment integrations, DESKVUE is one small box that does it all, simply and securely over IP. Users tailor their workspace by connecting a single keyboard, mouse, USB 3/2 devices, audio, and up to four 4K monitors. Optionally, one of the four monitors can be 5K. DESKVUE connects to physical systems via Emerald transmitters and virtual machines using RDP, PCoIP, PCoIP ultra. AV Wall is an additional feature set and means DESKVUE can now be used as a video wall product. A full set of APIs are added for control, along with video wall templates and direct connection to H264/265 sources. This will simplify and reduce equipment required as the video wall system is fully integrated with the KVM system.
User Interface Emerald On Screen Display (OSD)
Storage 512 GB CompatibilityBoxilla Managers, Emerald Transmitters, and Virtual machines (RDP, PCoIP, H.264/H.265)) Memory 16 GB Distance Supported 100m using CATx cabling Processor Intel Core i9 Processor 14900 vPro (24 Cores/36MB Cache/32T/up to 5.4GHz Turbo/65W) Power 65W AC Adapter, 4.5 mm Barrel; Input:100-240VAC, 1.5 Amps; Output:19.5VDC, 4.62 Amps Power Consumption: 90 Watts maximum TAA compliant yes Replaces EMD5004-R Connectors (4) DisplayPort Outputs: (3) 4K and (1) 5K; (3) USB 3.2 Gen 2x1, Type A (SuperSpeed USB); (1) USB 3.2 Gen 1x1, Type A (SuperSpeed USB); (1) USB-C, USB 3.2 Gen 2x2 (SuperSpeed USB); (1) 3.5 mm Analog Audio Output; (1) 3.5 mm Analog Microphone Input; (2) RJ-45 1Gbps Network Ports; (1) Power Input Dimensions 182 H x 36 W x 178 D mm Weight 1.34kg Mounting None Altitude Range Operating: <1,681m; Storage: <5,862m Humidity Operating: 20 to 80% (non-condensing); Storage: 5 to 95% (non-condensing) Heat Dissipation 306.9 BTU/h Shock (Maximum) Operating: 40 G†; Storage: 105 G† Vibration (Maximum) Operating: 0.26 GRMS; Storage: 1.37 GRMS Operating Temperature 10 to 35ºC Storage Temperature -40 to +65ºC
(1) Emerald DESKVUE Multi-Source TAA Receiver
(1) 19.5VDC, 4.62Amp, Desktop Power Supply (1) Power Cord DatabladeEmerald DESKVUE KVM Receiver Data Sheet
Emerald Unified KVM Family Data Sheet
ManualerEmerald DESKVUE KVM Receiver User Manual
