Desktop switching with high-quality Dual DVI-I video
The ServSwitch DT DVI MultiVideo Series supports the full DVI single link specification, allowing you to switch resolutions at up to 1920x1200 at 60Hz. With their dual head video functionality they are ideal for computers featuring two graphic outputs and consoles with two monitors besides the USB keyboard and mouse. The switches' circuitry architecture allows you to fine tune the signals depending on signal strength.
Transparent USB 2.0
The switches combine dual DVI or VGA video and audio signals together with transparent USB 2.0 signals to be switched. Switching is issued via push buttons on the front. Up to three USB peripherals like USB mouse, DVD writer, USB printer are supported via a built-in hub.
Emulated USB for keyboard and mouse
For easy hotkey switching, the DT DVI MultiVideo supports one emulated USB channel.
Stereo audio support
All models support stereo-audio signal switching for speakers and microphones. Audio channels can be switched independently from USB and video.
Resolution —
HDTV: 1080p;
DVI-D: 1920 x 1200;
Bandwidth: 1.5 Gbps
Video—
2-Port - DVI-I Connector for DVI-D Only;
4-Port - DVI-I Connector for DVI-D or VGA
Operating Systems Supported — Windows® 95/98/Me/XP, Windows NT®, Windows 2000, Mac® OS
Connectors —
KV9624A:
CPU side:
Video: (8) DVI-I;
USB: (4) USB Type B;
Audio: (8) 3.5mm stereo jacks;
Console side:
Video: (2) DVI-I;
USB workstation/device sharing: (4) USB Type A;
Audio: (2) 3.5mm stereo jacks
(1) barrel connector for power
Indicators — (1) power; (2) LEDs for port selection; (2) LEDs for CPU power
Control — Front-Panel Push Buttons or Hotkey commands
Power — External: 100 to 240 VAC / 5 VDC
Dimensions —
8.67" W, 5.14" D (5.34" D w/ DVI connectors), 2.45" (no feet included)
220mm W, 131mm D (135.7mm D w/ DVI connectors), 62.23mm (no feet included)
Weight — 1.86 kg
TAA compliant — YES
ServSwitch DT Series KVM Switch
Universal Power Supply, Output: 9-12 VDC, 1.5 A
(1) Power Cord
(1) Set of Rubber Feet
User Manual
Datablade
DT Series Desktop KVM Switch - Dual-Monitor DVI-D, USB Datablad
Manualer
|
